Depending on your company’s specification, Hightop can provide various polyester forming fabric. Below are some single layer forming fabric types available:
4-shed single layer forming fabric
The 4-shed single layer is the most common polyester forming fabric type used for papermaking. Example uses includes packing paper and cultural paper printing paper
5-shed single layer forming fabric
This type is typically used for packing paper or for culture or health paper
8-shed single layer forming fabric
The 8-shed layer type is ideal for packing for huge pieces. This can be used to make Kraft paper, corrugated boards or cardboards. As the layer is weave, it has excellent drainage, which would result to good stability as well as longer lifespan for the product.
The single layer forming fabric is ideal when using a fourdrinier paper machine.
| Model of Fabrics | Wire Diameter (mm) | Density (wire/cm) | Strength (N/cm) | Air Permeability (CFM) | |||
| Warp | Weft | Warp | Weft | Area of Surface | Joint | ||
| 25458 | 0.22 | 0.45 | 28.6 | 14.8 | ≥700 | ≥500 | 500 |
| 18458 | 0.27 | 0.45 | 21 | 18 | ≥700 | ≥500 | 500 |
| 25274 | 0.22 | 0.27 | 28 | 20 | ≥600 | ≥400 | 456 |
| 31204 | 0.18 | 0.20 | 35.2 | 33 | ≥600 | ≥380 | 282 |
| 16354 | 0.25 | 0.40 | 18 | 15 | ≥700 | ≥450 | 728 |
| 25305 | 0.22 | 0.30 | 27.8 | 22.4 | ≥700 | ≥450 | 440 |
